Connecting rod Yamaha DT 80 LC, TZR 80 LC (D.20) Italkit BC.5029

<p>Connecting Rod Italkit BC.5052 Montesa Enduro-Capra 250 H6-VB Cota 247</p><ul style="list-style-type:disc;"><li>Center-to-center Length (mm):116</li><li>Inner Diameter Small End (mm):20</li><li>Inner Diameter Big End (mm):26</li><li>Width Small End (mm):</li><li>Width Big End (mm):16</li><li>Crankpin Diameter (mm):20</li><li>Crankpin Length (mm):55</li><li>Piston Pin Cage (mm):16x20x17</li><li>Crankpin Cage (mm):20x26x16</li><li>Connecting Rod Washers (mm)</li></ul>

ITALKIT

HOT RODS

<p>Forged Italkit connecting rod for <strong>Honda NSR / CRM 125.</strong></p><p>Silver connecting rod head cage to <strong>withstand higher revolutions and load.</strong></p><p>Compatible with <strong>JC20 and JC22</strong> engines, it is ideal both for competition and for those who want a <strong>robust and reliable connecting rod.</strong></p>

ITALKIT

<p>Prox Connecting Rod 03.7220 for <strong>CAGIVA:</strong></p><ul><li>Mito 125 (94-07)</li><li>Mito SP 125 (08)</li><li>Planet 125 (98-03)</li><li>Raptor 125 (04-07)</li><li>Roadster 125 (95-99)</li><li>Supercity 125 (97-99)</li></ul>

PROX

<p>Italkit BC.1434R Connecting Rod <strong>Competition Machined</strong> Malossi-Polini 80 mm, width 12 mm, Ø18</p><p>Additionally, it is <strong>forged and equipped with silver cages</strong></p>

ITALKIT

<p>Reinforced Italkit connecting rod with silver cages.</p><p>For Gilera models 125 cc CRONO and CX 125</p><p><strong>Not valid for SP01/02</strong></p><ul style="list-style-type:disc;"><li>A=106</li><li>B=20</li><li>C=26</li><li>E=17</li><li><span class="ILfuVd">Ø = 20<br /></span></li><li><span class="ILfuVd">L=58.0</span></li><li><span class="ILfuVd">RST= 16x20x20</span></li><li><span class="ILfuVd">VZY=20x26x17</span></li></ul><p></p>

ITALKIT

<p>Italkit Connecting Rod BC.0252 for Bultaco Lobito 125cc 175cc - Sherpa T250 - Tralla 101-102 - Metralla 200cc - Mercurio 155</p><p>Rod measurements according to the sketch provided in photograph no. 2.</p><ul style="list-style-type:disc;"><li>A=116</li><li>B=20</li><li>C=26</li><li>E=16</li><li><span class="ILfuVd">Ø = 20/18<br /></span></li><li><span class="ILfuVd">L= 48</span></li><li><span class="ILfuVd">RST= 16x20x20</span></li><li><span class="ILfuVd">VZY=20x26x15</span></li></ul>

ITALKIT

<p>Connecting rod crankshaft AIRSAL stroke 45 (32087550)</p>

AIRSAL

<p>You can use this connecting rod kit to rebuild your old Honda RS250 crankshaft. It fits 13000-NX5-790 and 13000-NXA-610.</p><p>This VHM connecting rod kit includes two connecting rods, two lower needle cages, and washers.</p><p>The <strong>VHM</strong> connecting rods have been tested and used by many teams worldwide.</p><p>The standard connecting rod deforms ovally between 0.015-0.02mm, while the VHM connecting rod only deforms 0.005mm (due to high-strength material).</p><p>Additionally, it has a super finish, which ensures a smooth surface. This helps to prevent small fractures in the material.</p><ul style="list-style-type:disc;"><li>Less deformation</li><li>High fracture resistance</li></ul><p><strong>Compatible with standard crankshaft!!</strong></p>

VHM

<span><p>Reinforced Connecting Rod 90 mm Derbi Senda 50, GPR 50</p></span>

MALOSSI

<p>Italkit Connecting Rod BC.5051 for Bultaco 350 Alpina - Sherpa T</p><ul style="list-style-type:disc;"><li>A=116</li><li>B=24</li><li>C=26</li><li>E=17</li><li><span class="ILfuVd">Ø = 20<br /></span></li><li><span class="ILfuVd">L= 48.0<br /></span></li><li><span class="ILfuVd">RST= 20x24x24</span></li><li><span class="ILfuVd">VZY=20x26x17</span></li></ul>

ITALKIT

<p>Italkit Connecting Rod, <strong>machined</strong> for <strong>Aprilia RS125</strong> with <strong>double forged</strong> and <strong>hand-finished</strong>.</p><p>The connecting rod's head bearing with <strong>PEEK treatment</strong> provides <strong>30% less</strong> resistance, offering reliability and endurance at high revolutions.</p><p>Additionally, it features a high-performance <strong>silver cage</strong> at the connecting rod foot.</p><p>Top-of-the-line connecting rod for your Aprilia RS125, whether for street or competition.</p><p><span style="text-decoration:underline;"><strong>Connecting rod weight:</strong></span></p><ul style="list-style-type:disc;"><li>Bare 131 grams</li><li>Complete 266 grams</li></ul><p>Compatible with Rotax 122 and 123 engines.</p>

ITALKIT

<div class="rte"><p>Wössner Connecting Rod P2012 for KTM SX 125 07-18, EXC 125 07-16, SXS 125 2008, SX 144 07-08, SX 150 09-18, HUSABERG TE 125 12-13, and HUSQVARNA TC 125 14-18</p><p>With this connecting rod from Wössner's factory, we find superior quality and a perfect choice for replacing your motorcycle's stock connecting rod.</p><p> </p></div>

WOSSNER

<p>Italkit <strong>forged</strong> connecting rod for Aprilia 125 with Rotax 122 and 123 engine</p><p>The connecting rod's head bearing with <strong>PEEK treatment</strong> provides <strong>30% less</strong> resistance, offering reliability and durability at high revolutions.</p><p>Additionally, it features a high-performance <strong>silver cage</strong> at the small end of the rod.</p><p><span style="text-decoration:underline;"><strong>Connecting rod weight:</strong></span></p><ul style="list-style-type:disc;"><li>Naked 151 grams</li><li>Complete 286 grams</li></ul><p>Valid for Rotax 122 and 123 engines.</p>

ITALKIT

<table class="table-data-sheet table-responsive"> <tbody> <tr class="odd"> <td>Brand</td> <td>MONTESA</td> </tr> <tr class="even"> <td>Model</td> <td>Cota 247-Enduro 250 H6-250 VR</td> </tr> <tr class="odd"> <td>CODE</td> <td>BC.5047</td> </tr> <tr class="even"> <td>Length Between Centers (A)</td> <td>116</td> </tr> <tr class="odd"> <td>Foot Diameter (B)</td> <td>20</td> </tr> <tr class="even"> <td>Head Diameter (C)</td> <td>26</td> </tr> <tr class="odd"> <td>Head Width (E)</td> <td>16</td> </tr> <tr class="even"> <td>Piston Pin Diameter (Ø)</td> <td>20</td> </tr> <tr class="odd"> <td>Piston Pin Length (L)</td> <td>55</td> </tr> <tr class="even"> <td>Piston Cage (RST)</td> <td>16x20x20</td> </tr> <tr class="odd"> <td>Pin Cage (VZY)</td> <td>20x26x15</td> </tr> </tbody> </table>

ITALKIT

<p>PROX Connecting Rod 03.2021 for<strong> YAMAHA RD350 / YFZ 350 BANSHEE</strong></p><table width="300" cellspacing="1" cellpadding="2" border="0"><tbody><tr class="tda"><td style="width:170px;">Measurement A: Upper Diameter</td><td>: 21 mm</td></tr><tr class="tdb"><td style="width:170px;">Measurement B: Lower Diameter</td><td>: 29 mm</td></tr><tr class="tda"><td style="width:170px;">Measurement C: Average Length</td><td>: 110 mm</td></tr><tr class="tdb"><td style="width:170px;">Measurement D: Upper Width</td><td>: 18 mm</td></tr><tr class="tda"><td style="width:170px;">Measurement E: Lower Width</td><td>: 17 mm</td></tr><tr class="tdb"><td style="width:170px;">Measurement F: Total Length</td><td>: 142.5 mm</td></tr><tr class="tda"><td style="width:170px;">Measurement G: Interior Length</td><td>: 85 mm</td></tr></tbody></table>

PROX
