CONNECTING ROD HONDA 125 CR 88-07 PROX 03.1212

<p>ITALKIT Connecting Rod <strong>Machined Competition</strong> for Derbi 74 Cross TT/CR 81-82</p><p>Additionally, it is <strong>forged and features silver cages</strong></p><ul style="list-style-type:disc;"><li>Center-to-center length (mm): 90</li><li>Inner Ø Small end (mm): 16</li><li>Inner Ø Big end (mm): 22</li><li>Big end width (mm): 12</li><li>Crankpin Ø (mm): 16</li><li>Crankpin length (mm): 51</li><li>Piston pin cage (mm): 12x16x15</li><li>Crankpin cage (mm): 16x22x12</li></ul>

ITALKIT

<p>Connecting rod <strong>Machined with double forging</strong> and <strong>hand-finished</strong> with silver cages resistant to high revolutions and load.</p><p>Top-of-the-line connecting rod for your GPR75 for street or competition.</p><ul style="list-style-type:disc;"><li>A=95</li><li>B=16</li><li>C=24</li><li>E=12</li><li><span class="ILfuVd">Ø = 18<br /></span></li><li><span class="ILfuVd">L= 45.0</span></li><li><span class="ILfuVd">RST= 12x16x16</span></li><li><span class="ILfuVd">VZY=18x24x12</span></li></ul>

ITALKIT

<p>Italkit connecting rod for Derbi Senda 50cc and Derbi GPR 50cc Silver</p><ul style="list-style-type:disc;"><li>A=90</li><li>B=16</li><li>C=22</li><li>E=12.7</li><li><span class="ILfuVd">Ø = 16<br /></span></li><li><span class="ILfuVd">L=44.4</span></li><li><span class="ILfuVd">RST= 12x16x15</span></li><li><span class="ILfuVd">VZY=16x22x12</span></li></ul><p></p>

ITALKIT

<p>Reinforced Prox connecting rod for Yamaha DT R 125 (88-06) and Derbi GPR 125 2T</p><p>Prox <span class="product-reference right">03.2009</span></p>

PROX

<p>Italkit Connecting Rod for Montesa Cota 348-349.</p><p>With silver cages to withstand higher revolutions and increase reliability.</p><p>Check dimensions with photo No. 3</p><ul style="list-style-type:disc;"><li>A=124</li><li>B=22</li><li>C=26</li><li>E=16</li><li><span class="ILfuVd">Ø = 20<br /></span></li><li><span class="ILfuVd">L= 55<br /></span></li><li><span class="ILfuVd">RST= 18x22x22</span></li><li><span class="ILfuVd">VZY=20x26x16</span></li></ul>

ITALKIT

<div class="rte"><p>Wössner Connecting Rod P2012 for KTM SX 125 07-18, EXC 125 07-16, SXS 125 2008, SX 144 07-08, SX 150 09-18, HUSABERG TE 125 12-13, and HUSQVARNA TC 125 14-18</p><p>With this connecting rod from Wössner's factory, we find superior quality and a perfect choice for replacing your motorcycle's stock connecting rod.</p><p> </p></div>

WOSSNER

<p>Hot Rods Crankshaft Connecting Rod Kit 8147</p>

HOT RODS

<p>Italkit Connecting Rod BC.0252 for Bultaco Lobito 125cc 175cc - Sherpa T250 - Tralla 101-102 - Metralla 200cc - Mercurio 155</p><p>Rod measurements according to the sketch provided in photograph no. 2.</p><ul style="list-style-type:disc;"><li>A=116</li><li>B=20</li><li>C=26</li><li>E=16</li><li><span class="ILfuVd">Ø = 20/18<br /></span></li><li><span class="ILfuVd">L= 48</span></li><li><span class="ILfuVd">RST= 16x20x20</span></li><li><span class="ILfuVd">VZY=20x26x15</span></li></ul>

ITALKIT

<p>Connecting Rod Montesa Cota 242-304-307-309-311 Italkit BC.5046</p><p>With silver cages to withstand higher RPMs and increase reliability.</p><p>Check dimensions with photograph No.2</p><ul style="list-style-type:disc;"><li>A=116</li><li>B=20</li><li>C=26</li><li>E=16</li><li><span class="ILfuVd">Ø = 20<br /></span></li><li><span class="ILfuVd">L= 56<br /></span></li><li><span class="ILfuVd">RST= 16x20x20</span></li><li><span class="ILfuVd">VZY=20x26x16</span></li></ul>

ITALKIT

<p>Reinforced Italkit connecting rod with silver cages.</p><p>For Gilera models 125 cc SP01, SP02, and RX 125.</p><p>Not valid for Crono or CX 125.</p><ul style="list-style-type:disc;"><li>A=110</li><li>B=20</li><li>C=26</li><li>E=17</li><li><span class="ILfuVd">Ø = 20<br /></span></li><li><span class="ILfuVd">L=58.0</span></li><li><span class="ILfuVd">RST= 16x20x20</span></li><li><span class="ILfuVd">VZY=20x26x17</span></li></ul><p>Italkit BC.1651S</p>

ITALKIT

<p>Reinforced Italkit connecting rod with silver cages for Derbi GPR75.</p><ul style="list-style-type:disc;"><li>A=95</li><li>B=16</li><li>C=24</li><li>E=12</li><li><span class="ILfuVd">Ø = 18<br /></span></li><li><span class="ILfuVd">L= 45.0</span></li><li><span class="ILfuVd">RST= 12x16x16</span></li><li><span class="ILfuVd">VZY=18x24x12</span></li></ul>

ITALKIT

<p>Connecting rod <strong>ITALKIT</strong> with silver cages resistant to high revolutions and load.</p><p>For Honda NSR / MBX / CRM 75</p>

ITALKIT

<p>Prox Connecting Rod Honda 03.1200</p>

PROX

<span><p>Reinforced Connecting Rod 90 mm Derbi Senda 50, GPR 50</p></span>

MALOSSI

<p>Connecting Rod Montesa Crono 350-Enduro 360 H6-H7 Italkit BC.5098</p><ul style="list-style-type:disc;"><li>Length between centers (mm):124</li><li>Øint Small end (mm): 22</li><li>Øint Big end (mm): 29</li><li>Width Small end (mm):</li><li>Width Big end (mm):16</li><li>Ø Crank pin (mm):22</li><li>Crank pin Length (mm):64.4</li><li>Piston Pin Cage (mm):18x22x20</li><li>Crank Pin Cage (mm):22x29x16</li><li>Connecting Rod Shims (mm)</li></ul>

ITALKIT

<p>Italkit Connecting Rod, <strong>machined</strong> for <strong>Aprilia RS125</strong> with <strong>double forged</strong> and <strong>hand-finished</strong>.</p><p>The connecting rod's head bearing with <strong>PEEK treatment</strong> provides <strong>30% less</strong> resistance, offering reliability and endurance at high revolutions.</p><p>Additionally, it features a high-performance <strong>silver cage</strong> at the connecting rod foot.</p><p>Top-of-the-line connecting rod for your Aprilia RS125, whether for street or competition.</p><p><span style="text-decoration:underline;"><strong>Connecting rod weight:</strong></span></p><ul style="list-style-type:disc;"><li>Bare 131 grams</li><li>Complete 266 grams</li></ul><p>Compatible with Rotax 122 and 123 engines.</p>

ITALKIT
